Selectronic Solar Inverter SA32 2400w 20-34v(7000w surge) 240v

No Compromise
All the vital parameters of the SE32 are fully adjustable making it compatible with any remote power system. These parameters are easily changed as required via the front panel which has an illuminated display to tell you what is being adjusted. No need to compromise your power system performance. Of course, all the settings are retained when the inverter is powered down.

Displays
The display on the front panel of the SE32 gives you vital information about your power system. You are able to display INVERTER STATUS, AC VOLTS, AC AMPS and BATTERY VOLTS.
Also the SE32 will alert you to the cause of any inverter shutdown by beeping an alarm and displaying a message containing the reason for the shutdown. As a shutdown occurs, the SE32 stores the cause of the shutdown in an ?Alarm Log? allowing you to view at a later date the cause of up to the last one hundred inverter shutdowns.
The SE32 will shutdown and protect itself if the battery volts are too high or too low, the load on the inverter is too high, or the temperature of the inverter becomes too high.
A set of diagnostic readings can also be accessed to assist in remote troubleshooting.

Amp Hour Meter
When used with the optional external current shunt, the SA Series inverters will monitor all charge and discharge currents. The display will show a NETT current figure and continually calculate the charge in your battery. The SA Series inverters will also log MINIMUM BATTERY CHARGE each day for up to 30 days or each week up to 52 weeks, essential information for maximising battery life. DAILY PEAK CHARGING is also displayed - a consistent figure in this screen will indicate that charging sources are working correctly.

Control Outputs
Two outputs are supplied which can be configured to control external circuits. These outputs can be set to come on with TIME and DAY, INVERTER OVERLOAD or LOW BATTERY CHARGE (optional shunt required). Use a pump to fill a header tank once a week, control security lighting or start a generator, you imagination is the limit.

User Inputs
Two user inputs have many applications including generator warnings or security indicators on a battery room door.

Safety and Standards
At Selectronic, we are serious about your safety so we have built the SE32 to conform to the Australian standards AS3100 and AS3108 (for electrical equipment and isolating transformers). This means the SE32 can be safely integrated into any normal electrical system. Naturally the SE32 conforms to the requirements of the Electromagnetic Compatibility framework (C tick), which means low radio frequency interference.

Simplicity
Whilst the SE32 is a very sophisticated inverter, it does not require complex programming. In most cases the SE32 will perform perfectly well with the factory settings. Just connect it up, switch on and your power problems have disappeared.

Modular Construction
This important feature of the SE32 allows for quick and easy on site repairs by any authorised person. Inconvenient down time is minimised.

Fully Upgradable
Don?t lock yourself into an inverter that cannot expand with your remote power system needs. As your finances allow or as your needs change, the SE32 can be upgraded to Energy Management Mk II.
This system is a fully featured monitoring and control system that allows you to keep track of vital system parameters, perform control functions and allow remote communication. SA32 models which include the EM Mk II fitted ex factory are also available.

At fi rst glance Selectronic inverters may appear more expensive than competitors models, at Selectronic we have no problem with that, because we know that our product will outlast and out perform our competitors. We also believe that our products already meet the proposed Australia/New Zealand standard for inverters.

As an environmentally aware company, Selectronic are opposed to the ?throw away? philosophy adopted in many parts of today?s society. While our product will continue to perform, countless competitors products will simply be thrown into landfi ll, adding to society?s problems of waste and pollution.

If you care like we do, buy right, buy once.

Selectronic have a wealth of experience in providing reliable Inverter solutions to remote and leisure applications. A 100% Australian owned and operated company, we have been servicing the Australian electronics industry since 1964 and have produced many thousands of inverters to Australia, NZ and throughout Asia.

Selectronic has been the choice of professionals and project managers for years now, together with our ISO9001 quality accreditation for design and manufacturing, you can be sure our products are engineered to last.
